## What is Machine Learning

I decided to prepare and discuss machine learning algorithms in different series which is valuable and can be unique throughout the internet. I claim that there is a rare resource which is SIMPLE and COMPLETE in machine learning.

I want to explain how algorithms I machine learning are working by going through low-level explanation instead of just have a short glance on a high level. I believe this way can widen our perspective and prepare us to apply them correctly. Because having a high level and superficial theory about nice algorithm lead us nowhere, in return, if we know what is happening under the layer of this algorithm can help us to use them more properly.

For have a better understanding of machine learning I prefer to talk briefly about the whole story of machine learning.

Machine learning is a branch of computer science which has been extended from pattern recognition and artificial intelligence. Its meaning comes from where the computer can learn how to predict phenomena by the aid of training data which are sample data have been occurred in the past and machine tries to anticipate what is the result of an event according to having specific conditions. This learning process occurs in two different ways. One is supervised and another is unsupervised.

Supervised learning is to teach alphabetic to kid under the monitor of his teacher and unsupervised learning is such as the kid who tries to walk alone after trial and errors he will understand how to walk correctly. In a better instance, in supervised, we tend to classify objects but in unsupervised we actually do not know what we are looking for, we just study and watch some objects and we try to cluster them according to their similarity.

### Classification

Classification – Supervised: Assume a father show a dog to his son and then if son sees another race of dog can detect that it is dog but from another kind of dog. The goal was clear; son should see some dogs and his father told him that “it is dog” then he should detect dog –even from other color or race or size- in future.

### Clustering

Clustering – Unsupervised: But now the story is different, a father brings his son to the zoo and shows him different animals without telling him that what is their name. So his son just can categorize in his brain the various animals according to their color, size and etc. If in future he sees an animal which is similar to one of those animals, he can say that “this animal –which does not know its name- is similar to those animals that I have seen in the zoo on that cage.” So the goal is here that son should cluster new animal to another animal that he has seen by now.

Supervised has f(X) = y and there is a value or each feature while in unsupervised there is just (X) without knowing its f(X).

Result: as a result, finally we encounter two different examples of a problem to solve:

Supervised – Classification: According to past data which there are specific output value- target or dependent variable which is called “Y” for one or more than one features or independent variable which is called “X” or “X1, X2, …., Xn”. For example, there is a data set of patient information and we want to find whether a patient will get cancer or not; or what is the price of some object in near futures according to their changing price in the past.

## Linear Regression

In some problem, we have no limitation for “Y” value such as price prediction, but in others such as when we want to know what is the probability of cancer in one patient, we have to give a result between zero and one.

Y = aX + b

Y is a target value, dependent, output

a is regression coefficient, slope

X is independent value, feature, input

b is a constant value

I decided to make everything as KISS = Keep It Simple Stupid

Therefore I designed small data set by myself and we can study on it easily and then you can go to my GitHub and study according to real tutorial data set from a machine learning course. Click HERE for more info about this course.

This data set is based on the relation between study hours of students and their achieved grade. We draw a graph according to the above data and assign study hours to horizontal axis and grade to the vertical axis. You see I student study more they can gain a better grade. So after looking at this graph, we want to predict if one student study 8 hours how much would be his grade?

We need a line as the blue line to determine the progress of changing a grade based on study hours. Y and X are known by data set value, we just need a, b value to draw a blue line or “Prediction line”. No matter how much we are precise, it is sometimes impossible or difficult to draw a prediction line without error. The error rate in machine learning is inevitable; but we should find best a, b and minimize error rate to have an accurate output.

The vertical distance between the actual value which is a black star and predicted value on the blue line which is a yellow star is called “Prediction Error” or “Cost”. In order to calculate prediction error; we have to minus Prediction Error = Yactual – Ypredicted Yprediction = aX + b

Because we have more than one record in a data set, we need to generalize above formula to:

Sum of Squared Errors (SSE) = ½ Sum (YactualYpredicted)2

But we need to minimize SSE as far as possible, we learned in high school mathematics that we should derivate formula to make it optimum. Because we have two variable so we need two differentiations. Because we are working on a, b, so we should make partial differentiation. In partial differentiation based on “a”, others variable such as “X”, “Y” and “b” in SSE should be kept as constant.

Before study deeply on the above data set, we need to standardize – normalize or scaling value in order to have an equal range and/or variance. Because study hours are between (2,7) but the grade is between (50,70), so there is variance in their scale makes some difficulty to compare them.

The first step is that compute “cost function” based on Ө = [a, b], these “a” and “b” are values which we have selected randomly.

1. Select Ө = [a, b], a is slope and b is intercept randomly.
2. Compute “Cost Function”.
3. Compute “Gradient Descent” for Ө = [a, b].
1. anew = aold - r*∑ ∂SSE/∂a r is learning rate
• ∂SSE/∂a = -(Y-Yp)X
2. bnew = bold - r*∑ ∂SSE/∂b
• ∂SSE/∂b = -(Y-Yp)
4. Again Compute “Cost Function” Cost Function
5. Compare if new Cost Function value is less than before; if “Yes” so you are in right direction, lets continue.
6. Repeat and iterate step 3 to 5 until finding the best value.

** r is learning rate is the pace of learning, cost function should be decreased in every iteration and get convergence. If the cost function in each repeat with different a, b is decreased, so we selected suitable r.

## Using the code MATLAB

I used MATLAB R2012a (7.17.0.739)

### 1. Start to call Function"executed.m";

Firstly there is "executed.m", I called all of the function from here. In the first part, I loaded data from data.txt which is a very simple text. Then I standardize data with the mentioned formula above. Then I draw points according to new coordinates. Then I assume a=0, b=0 and computed "Cost Function", then I started to calculate best a, b by the aid of "Gradient Descent" with learning rater r=0.01 and 1500 iteration.

```clear ; close all; clc

%% ======================= Part 1: Load Data ==============================
fprintf('Plotting Data ...\n')

%% ======================= Part 2: Standardize Data =======================
% Standardize Data
data = standardizeData(data);
X = data(:, 1);
y = data(:, 2);
m = length(y); % number of training examples

%% ======================= Part 3: Plotting ===============================
% Plot Data
plotData(X, y);

fprintf('Program paused. Press enter to continue.\n');
pause;

%% =================== Part 4: Prediction Error - Copmute Cost ============

X = [ones(m, 1), data(:,1)]; % Add a column of ones to x
theta = zeros(2, 1); % initialize fitting parameters

iterations = 1500;
alpha = 0.01;

% compute and display initial cost
predictionError(X, y, theta)

%% =================== Part 5: Gradient descent ===========================
theta = gradientDescent(X, y, theta, alpha, iterations);

% print theta to screen
fprintf('Theta found by gradient descent: ');
fprintf('%f %f \n', theta(1), theta(2));

% Plot the linear fit
hold on; % keep previous plot visible
plot(X(:,2), X*theta, '-')
legend('Training data', 'Linear regression')
hold off % don't overlay any more plots on this figure```

### 2. Standardize "standardizeData.m"

```function [stdata] = standardizeData(data)
%Standardize Data

X = data(:, 1);
Y = data(:, 2);
m = length(Y); % number of training examples
stdata = zeros(m, 2); % initialize fitting parameters

% StdDev = SQRT( sum[(X-mean)^2/(n-1)]  )
meanX = mean(X);
stdX = std(X);

for i = 1:m

X(i) = ((X(i) - meanX)/stdX);
end

%Standardize(X) = X-mean /Std(X)

meanY = mean(Y);
stdY = std(Y);

for i = 1:m

Y(i) = ((Y(i) - meanY)/stdY);
end

stdata(:, 1)= X(:);
stdata(:, 2)=Y(:);```

### 3. Plot "plotData.m"

```function plotData(x, y)

figure; % open a new figure window

plot(x,y,'rx','MarkerSize',10);
ylabel('Profit');
xlabel('Population');

end```

Then you should click on "Enter".

### 4. Compute "Cost Function" "predictionError.m"

```function J = predictionError(X, y, theta)
%COMPUTECOST Compute cost for linear regression
%   J = COMPUTECOST(X, y, theta) computes the cost of using theta as the
%   parameter for linear regression to fit the data points in X and y

% Initialize some useful values

m = length(y); % number of training examples
%theta = zeros(2, 1); % initialize fitting parameters

% You need to return the following variables correctly

% ====================== YOUR CODE HERE ======================
% Instructions: Compute the cost of a particular choice of theta
%               You should set J to the cost.

J=1/(2*m)*sum((X*theta - y).^2);

% =========================================================================

end```

### 5. Compute theta(a, b) which build best predictio line by Gradient Descent, "gradientDescent.m"

```function [theta] = gradientDescent(X, y, theta, alpha, num_iters)
%   taking num_iters gradient steps with learning rate alpha

% Initialize some useful values
%m = length(y); % number of training examples
J_history = zeros(num_iters, 1);

m = length(y); % number of training examples

for iter = 1:num_iters

if iter == 1
J_history(iter) = predictionError(X, y, theta);

elseif iter > 1
A=X(:,2);
B=-(y-(X*theta));
C=B'*A;

DefSSEb = sum(B);
DefSSEa = sum(C);

bold=theta(1,1);
aold=theta(2,1);

theta(1,1) = (bold - (alpha*(DefSSEb/m)));
theta(2,1) = (aold - (alpha*(DefSSEa/m)));

J_history(iter) = predictionError(X, y, theta);
end

end

theta = theta(:);
end```

## Conclusion

I found Machine Learning very exciting, I decided to work on it.

Gradient Descent is the first and foremost step to learn machine learning. As summarize Machine learning is “getting data and work on data then give back a result which is called its prediction”.

Therefore, an error will occur 100%, the goal is using the machine for prediction –because of huge and big data, a machine can do it faster- but by observing error and try to select better prediction by gradient descent.

Gradient Descent story will not finish here in linear regression (with just one X), you will encounter it in the multivariable and neural network.
